| Electricity Requirement | 208~240VAC 50/60Hz |
Power Consumption
| 25W per channel |
Current
| Range: 0.5 - 5V programmable Accuracy: ±(0.05% RD + 0.05% FS) Resolution: 1mV Minimum Discharging Voltage: 1.5V
|
| Data Sampling | Time interval: 1 - 900s |
| Max. Measurement cycles | 9999 cycles |
| Max. Program steps | 9999 steps |
| Product Dimensions | 668mm W x 400mm D x 90mm H |
Channels & Test Modes
Recipe Maker
| Charge: constant current charge (CC), constant voltage charge (CV), constant current constant voltage charge(CCCV) Discharge: constant current discharge (CD), constant power discharge (CP), constant resistance discharge (CR) Rest & cycles
|
Programs & Software
Real-Time Mornitoring
| Various graphs and curves can be created by software based on user definition. (Voltage-time curve, current-time curve, capacity-voltage curve, loops times-charge/discharge capacity curve, loops times-charge/ discharge efficiency curve, etc) Data reports are created by software in excel format. A copy of MS Excel must be installed in order to export data. The user can easily compare the performance of the batteries tested in channels both visually and statistically.
|
| Protection and Auto-recover | If the power failure occurs during testing, the system will shut down all the operating channels. Once power is recovered, the system will automatically resume those stopped channels and ensure that the test is normally conducted, so that no cases will lose any data. |
DCR Testability
|
The DCR Testing feature enables the Hybrid PulsePower Characterization (HPPC) of the battery. Such function also provides the max/min voltage and current protection.
|
Temperature Measurement & Battery clips
| Brand new laptop with MS Window, MS Excel 2013 30 days free trial is included and latest version testing software are installed and calibrated for immediate use Up to 20 sets of analyzers can be simultaneously controlled by one PC Notice: We strongly suggest you keep an instant back of the collected data using an external hard drive.
|
| Compliance | Multiple battery analyzers with one laptop configuration and purchase possible. $300 will be deducted from the sales price if one analyzer is purchased without the basic laptop. Up to 20 battery analyzers can be controlled via one computer & software.
|
| Net Weight | 30 Kg (65 lbs) |
| Shipping Weight | 37 Kg (80 lbs) / Analyzer only: 70lbs |
| Shipping Dimensions | Analyzer: 33"(L) x 21"(W) x 9"(H) |
