Basic Info
Model NO.: CY-MSK-SFM-VT-LD
Structure: Desktop
Certification: CE, TUV
Type: Measurement Type
Transport Package: Wooden Box
Origin: Zhengzhou, China
Customized: Customized
Material: Alloy
Application: School, Lab
Trademark: CY
Specification: 105mm× 120mm× 160mm
HS Code: 85141090
Product Description
Digital Battery Electrode Paste/Slurry Viscosity Tester (10-10^5 mPa·s) -MSK-SFM-VT-LD
Introduction
The viscosity of battery electrode pasta/slurry plays an important role during the electrode
coating on current collector, it is necessary to use a tester to monitor and then adjust the
viscosity when mixing. This tester can also be used for other fluid or paste viscosity testing
if within the range 10mPa·s~10^5 mPa·s. (100mPa·s-10^6 mPa·s and 0.1Pa·s~200Pa·s is available
upon request)
Specification
Features
| Stepless Speed Adjustable
4 Type of Testing Spindles
10mPa·s~10^5 mPa·s by digital display |
| Power | 110V - 220V 50Hz/60Hz |
| Accuracy | ±2%(Newtonian fluid) |
| Dimension | 105mm×120mm×160mm |
| Net Weight | 2.5kg |
| Compliance | CE Certified |
| Shipping Size | 43x37x39cm |
| Shipping weight | 11 kg |
Standard Package
| Control Panel
4 Type of Testing Spindles
Stand support Base/Pool
Case |
