Application
Muffle furnace are mainly used in metallurgy, glass, heat treatment, li-ion battery anode materials, new energy, abrasive and other industries to determine material under the condition of a certain atmosphere of professional equipment.
Features
1. LCD touch screen with PID Programmable control
2. CE certified, quality warranty
3. High quality alumina fiber, good heat preservation effect
4. 30 steps Programmable and SCR accuracy temperature control
5. Clear heating element, no color greening changing
6. Low power, energy conservation and environmental protection
Technical parameters
Model | CY-M1400-8L |
Chamber model | Side Door |
Display | 7” LCD Touch Panel |
Limiting temperature | 1400℃ |
Working temperature | ≤1350℃ |
Heating rate | Suggestion 0~20℃/min |
Temperature accuracy | ±1℃ |
Inside chamber size | 200*200*200(mm) |
Heating element | High Purity SiC |
Thermal couple | S Type |
Temperature control | PID automatic control via SCR power control |
Heating curves | 30 steps programmable |
Chamber material | Alumina Fiber |
Rated power | 4.5 KW |
Working voltage | AC 220V, 50-60Hz |
Packing | PLY wood box |
Accessories | glove 1pair, crucible tongs 1pc, manual book |
